0015 3-Speed Circulator Pump w/ IFC, 1/20 HP, 115V
Brand: Taco
Part#: 0015-MSF3-IFC

Taco 0015-MSF3-IFC is a 3-Speed Circulator Pump and is designed for a wide range of applications in hydronic, radiant heating and other recirculation project types.

3-Speed switching capability of the 0015-MSF3-IFC Taco Circulator Pump provides a convenient way to match a wide combination of PEX / Copper tube diameters and length of runs. Taco 00R has the highest starting torque in its class and a removable, high-flow Integral Flow Check (IFC) that reduces pressure drop and prevents gravity flow.


Applications:
  • Hydronic Heating/Cooling
  • Radiant Heating
  • Zoning with Pumps
  • Hydro-Air Fan Coils
  • And many others

Cross-References:
  • The older Taco 00R-MSF1-IFC, 00R-MSF1-4IFC models;
  • Grundfos UPS15-58FC;
  • Armstrong Astro 50-3;
  • Wilo Star21SF.

Technical Specifications:
  • Flow Range (GPM): 0-18;
  • Head Range (FT): 0-21;
  • Minimum Fluid Temperature: 40˚F (4˚C);
  • Maximum Fluid Temperature: 230°F (110˚C);
  • Maximum Working Pressure: 125 psi;
  • Connection Sizes: 3/4”, 1”, 1-1/4”, 1-1/2” Flanged;
  • Voltage: 115V;
  • Hertz: 60Hz;
  • Phase: 1;
  • Amps @ Speed 1: 0.71A;
  • Amps @ Speed 2: 0.82A;
  • Amps @ Speed 3: 0.98A;
  • HP: 1/20HP;
  • RPM: 3250;
  • Motor Type: Permanent Split Capacitor Thermally Protected;

Warranty:
3 year manufacturer's warranty.
